Key Takeaways
- The CyberPower PDU44002 is the standout when outlet-level switching and ATS functionality matter; simpler metered PDUs are a better fit when monitoring is enough.
- Rack size is not just U count: the Sysracks 37U is the full-height enclosed option, while its 22U, 35-inch-deep counterpart favors a smaller footprint with room for deeper gear.
- The StarTech.com 42U open frame offers adjustable depth and access, but it does not provide the enclosure and physical barrier of a cabinet.
- Wall cabinets serve different space and access needs: the 18U mesh-door model emphasizes ventilation, while the 9U glass-door cabinet suits compact installations where visibility matters.
- Power compatibility outranks outlet count: match voltage, amperage, plug, connector types, and circuit capacity before choosing among the listed PDUs.
| data center equipment | Warranty |
|---|---|
| CyberPower PDU24004 Metered AT | 3-year limited |
| Eaton ePDU G3 Managed 16-Outle | — |
| Sysracks 37U 32-Inch-Deep Serv | 2 years |
| CyberPower PDU24002 Metered AT | 3-year limited |
| Valiant Power 1U Vertical Rack | 3 years |
| Tecmojo 18U Wall Mount Network | 3-year manufacturer warranty |
| 50 Pack M6 x 16mm Rack Mount C | — |
| CyberPower PDU44002 Switched A | 3-year limited |
| 30A Metered Rack PDU | — |
| Tecmojo 9U Wall-Mount Server C | 3 years |
| StarTech.com 42U 4-Post Open F | — |
| MT-VIKI 12U Server Cabinet Net | 2 years |
| Sysracks 22U 19-Inch Server Ra | — |
| Tecmojo 15U Wall-Mount Server | 3 years |
| ElaraBerry 2U Cantilever Serve | — |
More Details on Our Top Picks
CyberPower PDU24004 Metered ATS Power Distribution Unit
For single-corded servers or network equipment that need a backup power feed, the CyberPower PDU24004 stands out for automatic transfer between two AC sources. If the primary feed fails or becomes unstable, it switches to the alternate source, adding a layer of power continuity without requiring a second device power cord. Its 12 IEC C13 outlets and 1U form factor suit a rack with several compatible loads, while the LCD gives local power and device information.
Compared with the CyberPower PDU24002, this model uses 200–240V power and IEC outlets rather than 100–120V and NEMA outlets, so the choice depends on the rack’s electrical setup. The tradeoff is a 12A derated current limit, plus incompatibility with simulated sine wave sources. I’d choose it for compatible sine-wave feeds, not as a universal PDU.
Pros:- Automatically switches to a secondary AC source if the primary fails or becomes unstable.
- Provides 12 IEC C13 outlets in a 1U rackmount design.
- LCD displays power and device information.
- Upgradeable firmware supports future updates.
Cons:- Current is derated to 12A, limiting the usable load.
- Not compatible with simulated sine wave AC sources.
Best for: Data center operators with 200–240V sine-wave feeds who need automatic source switching for single-corded servers or network devices.
Not ideal for: Teams using simulated sine wave sources, or racks whose load requires more than 12A of usable current.
- Voltage:200–240V
- Current:15A, derated to 12A
- Outlets:12 IEC C13
- Inputs:Two IEC C14 plugs with 10-foot power cords
- Mounting:1U rackmount
- Display:Color-selectable LCD
- Power compatibility:Sine wave AC sources; not compatible with simulated sine wave sources
- Warranty:3-year limited
Our verdict“Choose the PDU24004 when your rack uses 200–240V sine-wave power and needs automatic backup-feed switching for single-corded equipment.”
Eaton ePDU G3 Managed 16-Outlet Power Distribution Unit, 120V, 12A (EMA112-10)
The Eaton ePDU G3 EMA112-10 is the strongest fit here when visibility and remote outlet control matter more than redundant inputs. Its outlet-level readings cover current, voltage, power, and energy, and you can switch or reboot individual outlets. That makes it easier to identify a hungry device or recover a locked-up unit without cycling power to the rest of the rack. The LCD supports local setup, and its stated 140°F maximum ambient operating temperature suits installations that run warmer than typical office spaces.
Compared with the CyberPower PDU24004, Eaton offers more detailed outlet management but not automatic transfer between two power sources. It also differs from that model’s IEC outlets: the EMA112-10 is built around 120V, 5-15R connections. That restricts where it fits, and its 12A input calls for careful load planning. Choose it for managed 120V deployments, not high-voltage racks.
Pros:- Measures current, voltage, power, and energy at each outlet.
- Supports individual outlet switching and reboot control.
- LCD display enables local setup.
- Supports daisy chaining up to four devices on one network connection.
Cons:- Limited to 120V single-phase input and 5-15R outlets.
- The 12A input may constrain the total connected load.
Best for: IT teams managing 120V racks that need outlet-by-outlet energy data and the ability to remotely reboot individual devices.
Not ideal for: Operators with 200–240V equipment, non-5-15P power requirements, or a need for automatic transfer between redundant sources.
- Model:EMA112-10
- Input:5-15P, 12A, 120V, single phase
- Outputs:16 x 5-15R outlets
- Metering accuracy:±1% at outlet level
- Maximum ambient operating temperature:140°F (60°C)
- Dimensions:2.6 x 2.1 x 66.5 inches
- Weight:13 pounds
- Display:LCD pixel display
Our verdict“Pick the Eaton when outlet-level monitoring and reboot control are priorities in a 120V rack.”
Sysracks 37U 32-Inch-Deep Server Rack Cabinet
The Sysracks 37U cabinet makes the most sense for a site that needs a substantial equipment enclosure rather than another standalone power strip. Its 32-inch mounting depth accommodates servers, storage, UPS units, and networking gear, while a stated 1,600-pound static load supports a sizable installed system. Four thermostat-controlled roof fans and an LCD add temperature-aware cooling, and the included shelf, eight-outlet PDU, cable-entry brushes, casters, and leveling feet reduce the number of separate rack accessories to source.
Unlike the CyberPower PDU24004, which focuses on redundant power switching in 1U, this is a full 37U cabinet with basic included power distribution. That bundled approach is useful, but the included PDU does not replace a managed or ATS unit when those functions are needed. The cabinet also weighs 68 pounds and takes up a 24-by-32-inch floor footprint, so it is less suited to cramped rooms or frequent relocation.
Pros:- 37U capacity and 32-inch mounting depth suit a broad mix of rack equipment.
- Four thermostat-controlled roof fans include an LCD display.
- Includes an eight-outlet PDU, fixed shelf, casters, leveling feet, and cable-entry brushes.
- Rated for a maximum static load of 1,600 pounds.
Cons:- The 68-pound cabinet can be cumbersome to position.
- Its 24-by-32-inch footprint requires meaningful floor space.
- The included PDU does not provide the ATS function of the CyberPower PDU24004.
Best for: Small data rooms and IT teams building a floor-standing 19-inch rack for servers, storage, UPS equipment, and networking hardware.
Not ideal for: Buyers with limited floor space, frequent rack moves, or a need for advanced managed or redundant power distribution included.
- Rack size:37U
- Mounting width:19 inches
- Dimensions:24 W x 32 D x 74 H inches
- Weight:68 pounds
- Maximum static load:1,600 pounds (725 kg)
- Cooling:Four thermostat-controlled roof fans with LCD display
- Included accessories:8-outlet PDU, fixed shelf, locking casters, leveling feet, cable-entry brushes, and mounting hardware
- Warranty:2 years
Our verdict“Choose this Sysracks cabinet when you need a roomy, accessory-rich floor rack and have space to accommodate its depth and weight.”
CyberPower PDU24002 Metered ATS Power Distribution Unit
When a rack runs on 100–120V and uses NEMA connections, the CyberPower PDU24002 brings automatic transfer protection to single-corded equipment in a 1U unit. It switches between two power sources if the primary feed fails or becomes unstable, while its color-selectable LCD shows amperage, voltage, power, and IP address. Ten NEMA 5-20R outlets provide room for compatible network and server devices, and upgradeable firmware offers a path for updates.
This is the voltage-side counterpart to the CyberPower PDU24004: the PDU24002 uses NEMA outlets and a 100–120V input, while the PDU24004 is for 200–240V and IEC C13 loads. The PDU24002’s 20A rating is derated to 16A, so capacity still needs close attention. Like its sibling, it is incompatible with simulated sine wave AC sources; it is not the right match for every UPS or power setup.
Pros:- Automatically transfers between two power sources when the primary feed fails or becomes unstable.
- Provides 10 NEMA 5-20R outlets in a 1U rackmount unit.
- LCD shows amperage, voltage, power, and IP address.
- Upgradeable firmware supports updates.
Cons:- The 20A rating is derated to 16A.
- Not compatible with simulated sine wave AC sources.
Best for: Operators with 100–120V racks and NEMA 5-20R equipment who need automatic transfer between two compatible power sources.
Not ideal for: Teams using 200–240V IEC equipment, simulated sine wave sources, or loads that exceed the 16A derated limit.
- Input voltage:100–120V
- Amperage:20A, derated to 16A
- Maximum power:1,920W
- Outlets:10 NEMA 5-20R
- Input connectors:2 x NEMA L5-20P
- Power cord length:10 feet
- Form factor:1U rackmount
- Warranty:3-year limited
Our verdict“Choose the PDU24002 for ATS protection in a compatible 120V NEMA rack, and choose the PDU24004 instead for 200–240V IEC equipment.”
Valiant Power 1U Vertical Rackmount PDU with Surge Protection (220V/50A, L6-50P Input, 4x C13 & 4x C19 Outlets)
The Valiant Power PDU is aimed at high-current, single-phase installations where a 50A input and a mix of C13 and C19 connections matter more than outlet-level control. Its eight outlets—four C13 and four C19—let a rack serve different equipment connector needs, while 20,000-joule surge protection adds protection against surges. The switchless design also removes an easy-to-hit power switch from the unit, reducing the chance of an accidental cutoff.
Compared with the CyberPower PDU24004, this Valiant model offers a higher stated input-current capacity and C19 outlets, but it does not provide automatic transfer between two power sources or an LCD for power monitoring. The lack of a manual cutoff switch can also complicate local shutdowns. Its NEMA L6-50P input and 220–240V single-phase design demand a matching supply, so this is a specialized fit rather than a general-purpose rack PDU.
Pros:- 50A maximum input current for compatible high-current installations.
- Combines four C13 and four C19 outlets.
- Built-in 20,000-joule surge protection.
- Metal housing supports rack, wall, or workbench mounting.
Cons:- Switchless design provides no manual power cutoff on the PDU.
- Limited to single-phase applications and a compatible L6-50P supply.
- Does not offer the automatic source transfer found on the CyberPower PDU24004.
Best for: Operators of high-density 220–240V single-phase racks, including mining or networking setups, that need C13 and C19 outlets with surge protection.
Not ideal for: Sites that need automatic source transfer, outlet-level monitoring, a manual power switch, or a different input connector and voltage setup.
- Input plug:NEMA L6-50P
- Input voltage:220–240V AC
- Maximum input current:50A
- Outlets:4 x C13 and 4 x C19
- Surge protection:20,000 joules
- Form factor:1U vertical rackmount
- Cord length:6 feet (2 m)
- Warranty:3 years
Our verdict“Pick the Valiant Power unit for a compatible high-current 220–240V rack that needs mixed C13/C19 outlets and surge protection, not ATS features.”
Tecmojo 18U Wall Mount Network Cabinet for 19″ IT Equipment with Lockable Mesh Door, Cooling Fan, and Side Panels
I’d choose this 18U wall-mount cabinet when floor space is scarce but a small network setup needs airflow and room to grow. Its mesh door and built-in fan provide more active ventilation than the Tecmojo 9U glass-door cabinet, which may suit quieter, smaller installations better. Adjustable rails, removable side panels, and a reversible front door also give installers more options for access and cable routing. The tradeoff is depth: the 14.2-inch mounting depth rules out some full-depth server hardware, even though the cabinet itself is 34.76 inches high. It supports up to 110 pounds, but that capacity does not remove the need to mount it securely to a suitable wall. Assembly is required, too, so I’d reserve this for buyers prepared to plan both mounting and equipment fit.
Pros:- Mesh door and built-in fan support airflow around active network gear.
- Adjustable rails and removable side panels make mounting and cable access more flexible.
- Reversible front door accommodates different room layouts.
- Supports up to 110 lb and lists PCI, HIPAA, and EIA/ECA-310-E compliance.
Cons:- 14.2-inch maximum mounting depth restricts compatibility with deeper equipment.
- Assembly is required before installation.
- A wall must safely support the cabinet and installed equipment.
Best for: Small offices, classrooms, and retail sites that need a ventilated wall-mounted rack for shallow network equipment and have a properly rated mounting surface.
Not ideal for: Teams installing deep servers or other equipment requiring more than 14.2 inches of mounting depth, or buyers who need a ready-to-use cabinet without assembly.
- Rack capacity:18U
- Mounting type:Wall mount
- Equipment capacity:110 lb (50 kg)
- Maximum mounting depth:14.2 in
- Dimensions:21.65 × 17.72 × 34.76 in
- Material:Cold-rolled steel
- Ventilation:Built-in cooling fan and mesh door
- Warranty:3-year manufacturer warranty
Our verdict“Choose this cabinet for a ventilated, space-saving home for shallow network gear; skip it if your equipment needs deeper rails.”
50 Pack M6 x 16mm Rack Mount Cage Nuts, Screws & Washers
This kit earns a place as a practical rack-installation essential, rather than a substitute for a cabinet or power unit. The set supplies 50 M6 cage nuts, screws, and washers for standard 19-inch racks, plus cable ties for tidying wiring during installation. That makes it a useful companion to larger enclosures such as the Sysracks 37U 32-Inch-Deep Server Rack Cabinet, where mounting hardware and cable organization are part of the setup work. Its black zinc-plated carbon steel is intended for indoor or semi-outdoor use, not exposed outdoor conditions. The Phillips-head screws also call for a careful hand: excessive torque can strip them. I’d select it when the rack uses M6 hardware and a consolidated kit is more useful than sourcing fasteners separately; check thread compatibility before ordering.
Pros:- Includes 50 sets of M6 cage nuts, screws, and washers for standard rack installation.
- Cable ties provide a handy extra for organizing wiring during setup.
- Black zinc-plated carbon steel is suited to indoor and semi-outdoor use.
- Snap-on cage nuts can be installed with basic hand tools.
Cons:- M6 hardware will not fit racks that require another thread size.
- Phillips-head screws may strip if over-tightened.
- Finish is not specified for heavy outdoor exposure.
Best for: IT installers and rack owners fitting standard 19-inch equipment that uses M6 cage nuts and wants mounting fasteners and cable ties in one kit.
Not ideal for: Buyers with racks requiring a different thread size, or installations exposed to harsh outdoor conditions or requiring heavy-duty corrosion protection.
- Quantity:50-pack
- Thread size:M6
- Screw length:16 mm
- Material:Carbon steel
- Finish:Black zinc plated
- Compatibility:Standard 19-inch server racks
- Included components:Cage nuts, screws, washers, and cable ties
Our verdict“Buy this kit when your 19-inch rack takes M6 hardware and you want fasteners plus cable ties together.”
CyberPower PDU44002 Switched ATS Power Distribution Unit
For single-corded equipment that needs a backup source, I’d favor the CyberPower PDU44002 over the 30A metered rack PDU: its defining job is automatic transfer between two power inputs, not simply distributing a higher-capacity feed. The 10 remotely managed outlets, LCD, and event notifications give administrators visibility and control when power conditions change. Its 1U form factor also uses little rack space. The limit is its electrical envelope: it accepts 100–120 V and is rated at 20 A, derated to 16 A, with 2,000 W maximum output. That makes it a poor fit for loads that need the 30A unit’s 120–240 V input or 7.2 kW capacity. It also is not compatible with simulated sine wave AC sources, so source compatibility needs checking before deployment.
Pros:- Automatically switches between two power sources when the primary source fails or becomes unstable.
- Provides 10 remotely managed outlets with local and remote monitoring.
- LCD status display and power-event notifications support quicker response to supply issues.
- 1U rackmount design conserves rack space.
Cons:- Capacity is limited to 16 A after derating and 2,000 W.
- Limited to 100–120 V input, unlike the 30A metered rack PDU’s 120–240 V range.
- Not compatible with simulated sine wave AC sources.
Best for: Small server-room and network administrators who need automatic source switching and remote outlet oversight for single-corded 100–120 V equipment.
Not ideal for: Operators powering high-load 120–240 V equipment, needing more than 16 A of derated capacity, or using simulated sine wave AC sources.
- Form factor:1U rackmount
- Input voltage:100–120 V
- Current:20 A; derated to 16 A
- Maximum wattage:2,000 W
- Outlets:10 × NEMA 5-20R
- Input connectors:2 × NEMA L5-20P
- Power cord length:10 ft
- Warranty:3-year limited
Our verdict“Choose it for managed 100–120 V equipment that needs automatic backup-source switching, not for high-capacity loads.”
30A Metered Rack PDU, L6-30P Power Distribution Unit with 8 Outlets (6 C13 & 2 C19), 120-240V 7.2kW Server Rack Power Strip with Aluminum Alloy Housing and 6ft Cord
When the rack needs a substantial power feed rather than automatic source transfer, this 30A rack PDU is the stronger match than the CyberPower PDU44002. Its stated 7.2 kW capacity, 120–240 V input, and mix of six C13 and two C19 outlets accommodate a range of server and network-device connections. The aluminum-alloy housing and air circuit breaker add a sturdy enclosure and overload protection, while the 6-foot cord offers some flexibility in rack placement. The tradeoff is a focused outlet count: eight connections may not cover a dense rack, and the L6-30P input requires a compatible supply. Unlike the CyberPower ATS, this unit’s listed features do not include redundant-source switching or remote outlet management. I’d choose it for compatible high-load distribution, not for power failover or remote control.
Pros:- Rated for up to 7.2 kW and 30 A for higher-load rack power distribution.
- Six C13 and two C19 outlets serve a mix of equipment connections.
- Air circuit breaker provides overload protection.
- Aluminum-alloy housing and a 6-foot cord support rack installation.
Cons:- Eight outlets may be insufficient for a densely populated rack.
- L6-30P input requires a compatible power connection.
- Listed features do not include the CyberPower PDU44002’s automatic source switching or remote outlet control.
Best for: Data-center and server-room operators with a compatible L6-30P supply who need high-capacity distribution across C13 and C19 equipment.
Not ideal for: Buyers who need automatic failover, remotely switched outlets, more than eight outlets, or a supply that does not match the L6-30P input.
- Outlet count and types:8 total: 6 × C13 and 2 × C19
- Input voltage:120–240 V
- Maximum current:30 A
- Maximum power:7.2 kW
- Plug type:L6-30P
- Cord length:6 ft
- Enclosure material:Aluminum alloy
- Mounting type:Rack mountable
Our verdict“Pick this PDU for compatible 30 A rack power and C13/C19 connections, but choose an ATS when power-source failover is the priority.”
Tecmojo 9U Wall-Mount Server Cabinet with Lockable Glass Door and Side Panels
For a small network or A/V installation, this 9U wall-mount cabinet saves floor space without taking up as much wall area as the Tecmojo 18U cabinet. The lockable glass door and side panels keep equipment enclosed while leaving the front visible, which can be useful when checking status indicators without opening the cabinet. Numbered U positions and adjustable rails make equipment placement clearer, and cable access panels help keep wiring manageable. Its shared 110-pound capacity is generous for a compact enclosure, but the 14.2-inch mounting depth remains the deciding limit: it is for shallow 19-inch IT or A/V equipment, not deep servers. Assembly is required, and buyers must plan a secure wall installation. Compared with the mesh-door 18U Tecmojo, this is the tidier, smaller option, but it offers less rack space and no listed built-in fan.
Pros:- Compact 9U wall-mount format preserves floor space.
- Lockable glass door and side panels enclose equipment while keeping the front visible.
- Adjustable rails and numbered U positions help with equipment placement.
- Supports up to 110 lb and includes cable access panels.
Cons:- Maximum mounting depth of 14.2 inches excludes many deeper devices.
- Assembly is required.
- No built-in fan is listed, unlike the Tecmojo 18U mesh-door cabinet.
Best for: Small offices, shops, and A/V installers who need a lockable, shallow-depth cabinet for a modest amount of 19-inch equipment.
Not ideal for: Teams with deep servers, growing equipment inventories that need more than 9U, or installations where active ventilation is a requirement.
- Rack capacity:9U
- Mounting type:Wall mount
- Dimensions:19.02 × 21.65 × 17.72 in
- Maximum mounting depth:14.2 in
- Equipment capacity:110 lb (50 kg)
- Material:Cold-rolled alloy steel
- Door and panels:Lockable glass door and lockable side panels
- Warranty:3 years
Our verdict“Choose this cabinet for a compact, lockable home for shallow network or A/V gear; select the 18U Tecmojo if you need more space and airflow.”
StarTech.com 42U 4-Post Open Frame Server Rack, Adjustable 22–40 in. Depth
For a growing equipment lineup, I’d put the StarTech.com 42U ahead of the shorter Sysracks 22U cabinet: its 42U capacity and 22–40-inch adjustable depth leave more room to mix rack gear of different sizes. Its cold-rolled steel frame has a stated stationary capacity of 1,320 pounds, while casters, leveling feet, and floor-mounting hardware let buyers choose how to position it. Included cable hooks and mounting hardware also reduce the need to source basic setup parts separately.
The tradeoff is its open-frame design: unlike enclosed cabinets such as the Sysracks 22U, it does not offer a locking door or side panels for physical security. Assembly is required, and the rack needs a suitable equipment room because it stands more than six feet tall with casters. I’d choose it for accessible, expandable installations, not for spaces where enclosed equipment protection is a priority.
Pros:- 42U capacity and adjustable 22–40-inch depth accommodate a broad range of rack equipment
- Stationary load capacity is rated at 1,320 pounds
- Includes casters, leveling feet, and floor-mounting hardware for different placement needs
- Cable hooks and mounting hardware are included
Cons:- Open sides and frame do not provide cabinet-style physical security
- Requires assembly before equipment can be installed
- Its 80.3-inch height with casters calls for ample vertical clearance
Best for: IT teams and AV installers building a full-height rack with mixed-depth 19-inch equipment and a dedicated, access-controlled equipment room
Not ideal for: Small offices or shared spaces that need a lockable enclosure, or buyers who need a rack that arrives assembled
- Rack height:42U
- Mounting width:19 inches
- Adjustable depth:22–40 inches
- Height:80.3 inches with casters; 78 inches without casters
- Stationary weight capacity:1,320 pounds
- Material:Cold-rolled steel
- Included accessories:Casters, leveling feet, cage nuts, screws, cable management hooks, and assembly tools
- Standards:EIA/ECA-310-E, IEC 60297, DIN 40494
Our verdict“Choose the StarTech.com when you need an adaptable, high-capacity open rack and can manage security separately.”
MT-VIKI 12U Server Cabinet Network Rack with Moving Wheels
The MT-VIKI 12U suits a small network closet or office that needs an enclosed rack without giving up convenient access. Its locking front door and quick-open side panels make it a more security-minded choice than the open-frame StarTech.com 42U, while the included wheels can help with repositioning during setup or service. A supplied 12-inch shelf is useful for equipment that does not mount directly to the rails, and the cabinet supports standard 19-inch gear.
Its main limitation is 23.6-inch cabinet depth, which can rule out deeper servers even when the rack’s overall footprint seems manageable. The 132-pound capacity also places it well below the heavy-duty Sysracks 22U cabinet’s 1,600-pound static rating. I’d choose the MT-VIKI for lighter, compact networking setups where access and a lockable enclosure matter more than server depth or a large equipment load.
Pros:- Locking front door adds a layer of physical access control
- Quick-open side panels make maintenance and cable access easier
- Includes a 12-inch rack shelf and moving wheels
- 0.8 mm SPCC cold-rolled steel construction
Cons:- 23.6-inch cabinet depth may not fit deeper server equipment
- 132-pound capacity is far below the Sysracks 22U cabinet’s stated static load
- 12U provides less expansion space than larger floor-standing racks
Best for: Small-office IT administrators or installers housing switches, patch panels, and other shallow 19-inch equipment in a lockable cabinet
Not ideal for: Teams installing deep servers or heavy equipment that exceeds the cabinet’s 132-pound capacity
- Rack capacity:12U
- Dimensions:23.6 × 25.5 × 23.6 inches (W × H × D)
- Material:0.8 mm SPCC cold-rolled steel
- Weight capacity:132 pounds (60 kg)
- Mounting type:Wall mount
- Included accessories:One 12-inch-deep rack shelf and moving wheels
- Warranty:2 years
Our verdict“Pick the MT-VIKI for a compact, lockable network cabinet when your equipment is shallow and the load is modest.”
Sysracks 22U 19-Inch Server Rack Cabinet, 35-Inch Deep
The Sysracks 22U is a practical pick for buyers who want a floor cabinet supplied with several core rack accessories. It comes with four cooling fans, an 8-outlet PDU, a fixed shelf, cable-entry brushes, and mounting hardware, so fewer basic components need to be sourced separately. Its 35-inch depth and 1,600-pound static load rating also make it a more substantial equipment platform than the compact MT-VIKI 12U, which is designed around a much smaller capacity and footprint.
That capability comes with a space and handling cost: the cabinet measures 24 × 35 × 42 inches and weighs 200 pounds. I would plan its placement before delivery rather than treating it like a movable office cabinet. It also offers only 22U, so buyers expecting a tall installation may prefer the StarTech.com 42U open rack, accepting that it lacks this cabinet’s enclosure and included cooling and power accessories.
Pros:- Includes four cooling fans and an 8-outlet PDU
- 1,600-pound static load capacity supports substantial equipment loads
- 35-inch depth accommodates equipment that may not fit compact cabinets
- Ships with a fixed shelf, cable-entry brushes, casters, leveling feet, and mounting hardware
Cons:- The 200-pound cabinet can be difficult to position
- Requires floor space for its 24 × 35 × 42-inch dimensions
- 22U capacity is less than the 42U StarTech.com open rack
Best for: Small server-room teams that need a 35-inch-deep enclosed rack with bundled cooling, power distribution, and mounting accessories
Not ideal for: Buyers with limited floor space, a need for frequent rack relocation, or an installation requiring more than 22U
- Rack capacity:22U
- Dimensions:24 × 35 × 42 inches
- Mounting standard:19-inch ANSI/EIA-310
- Maximum static load:1,600 pounds (725 kg)
- Material:Alloy steel
- Cooling:Four fans
- Included accessories:8-outlet PDU, fixed shelf, locking casters, leveling feet, cable-entry brushes, and mounting hardware
- Item weight:200 pounds
Our verdict“Choose the Sysracks 22U if you want a sturdy floor cabinet with cooling and power accessories included and have room to place it.”
Tecmojo 15U Wall-Mount Server Rack Cabinet, 23.6-Inch Depth, Glass Door
The Tecmojo 15U gives buyers a middle ground between the small MT-VIKI 12U cabinet and a full floor rack: it offers 15U of enclosed space, lockable panels, removable sides, and two top-mounted fans. Its glass door lets staff see equipment without opening the cabinet, while included casters provide another placement option. Compared with the MT-VIKI, it offers a higher stated wall-mounted capacity of 176 pounds and a three-year warranty.
The key fit check is maximum mounting depth: 21.3 inches. That limits the server models it can house, even though the cabinet itself is 23.6 inches deep. Its weight rating also changes by installation: 176 pounds when wall-mounted versus 350 pounds floor-mounted. I’d select it for a modest, shallow network or AV setup that benefits from a lockable enclosure, but not for deeper servers or a wall installation carrying a heavy equipment load.
Pros:- 15U capacity offers more rack space than the MT-VIKI 12U cabinet
- Lockable glass door and side panels help control access while keeping equipment visible
- Two top-mounted fans support cabinet ventilation
- Removable sides and included casters provide setup flexibility
Cons:- 21.3-inch maximum mounting depth excludes many deeper server configurations
- Wall-mounted capacity is limited to 176 pounds, below its 350-pound floor-mounted rating
- At 78 pounds, the cabinet itself requires planning for installation and handling
Best for: Office network installers who need a lockable 15U enclosure for shallow 19-inch switches, patch panels, or AV equipment
Not ideal for: Data center teams installing deep servers or buyers who need to mount a load above 176 pounds on a wall
- Rack capacity:15U
- Dimensions:23.6 × 23.6 × 30.3 inches (D × W × H)
- Maximum mounting depth:21.3 inches
- Weight capacity:176 pounds wall-mounted; 350 pounds floor-mounted
- Cooling:Two top-mounted fans
- Material and door:Alloy steel cabinet with glass door
- Equipment compatibility:Standard 19-inch rack equipment
- Warranty:3 years
Our verdict“Choose the Tecmojo 15U for a lockable, ventilated wall cabinet only if your equipment fits within its 21.3-inch mounting depth and wall-load limit.”
ElaraBerry 2U Cantilever Server Rack Shelf, 19-Inch, 10-Inch Deep, 2-Piece Set, Black
Not every rack needs another cabinet; sometimes the missing piece is a shelf for equipment without rack-mount ears. The ElaraBerry set supplies two vented 2U shelves with adjustable mounting posts and a center-weighted design, giving buyers flexibility to position shallow accessories in a standard 19-inch rack or network cabinet. Its 110-pound stated capacity is useful for compatible equipment, and the vents avoid the solid-platform airflow blockage that can be an issue in a tightly packed rack.
These shelves are a complement to a rack, not a substitute for one: their 10-inch depth sharply limits what they can support. Compared with the included fixed shelf in the Sysracks 22U cabinet, this set offers two separate shelf pieces and adaptable mounting, but buyers must supply compatible rack space. I’d reserve it for shallow peripherals and accessories, not deep servers or equipment whose weight distribution does not suit a cantilever shelf.
Pros:- Two shelves provide flexible placement across a compatible rack
- Vented construction allows airflow through the shelf
- Adjustable mounting posts accommodate different rack configurations
- Stated capacity of 110 pounds
Cons:- 10-inch depth is unsuitable for most full-size servers
- Requires an existing compatible 19-inch rack or cabinet
- Cantilever support makes equipment fit and load placement important
Best for: Rack owners adding shallow modems, small network appliances, or other compatible accessories to an existing 19-inch rack
Not ideal for: Buyers needing support for deep servers, or anyone who needs a complete rack rather than add-on shelves
- Rack width:19 inches
- Rack height:2U
- Shelf depth:10 inches
- Capacity:110 pounds
- Material:Iron
- Design:Two-piece, center-weighted, vented
- Package contents:Two server shelves
- Item weight:5.78 pounds
Our verdict“Buy the ElaraBerry set to add flexible shelf space for shallow accessories, not to support deep server hardware.”
How We Picked
I compared these 15 products as parts of a data center or network rack setup, rather than treating every item as a substitute for every other one. The main criteria were power compatibility and control, rack capacity and depth, mounting options, access and airflow, and the practical role each product can fill. A switched ATS PDU ranks ahead of basic distribution when its control features solve a real operational need, but it is not automatically the right choice for a simple rack. For cabinets and frames, I weighed usable space, installation flexibility, and whether the design is open, enclosed, wall-mounted, or mobile.
The ranking reflects how broadly useful each product is for its intended job, how clearly its listed features support that job, and what limitations buyers need to plan around. Power and rack infrastructure lead because they shape compatibility and future expansion; mounting hardware and shelves are useful supporting purchases but cannot replace a correctly sized rack or power plan. I also distinguish products by their likely use case instead of presenting them as interchangeable. Buyers should verify current manufacturer specifications and site requirements, particularly electrical ratings, rack dimensions, load limits, and included installation hardware.
Factors to Consider When Choosing Best Data Center Equipment
Before choosing equipment, I would map the installation as a system: incoming power, rack layout, equipment dimensions, heat removal, and the people who need access. A product can be well suited to one part of that system and still be wrong for the room or circuit. These factors help prevent mismatches that a feature comparison alone will not catch.
Match the PDU to the electrical circuit
Start with the facility supply, not the outlet count printed on a PDU. Confirm voltage, amperage, plug type, phase where relevant, and the capacity of the circuit that will feed it. Then compare the PDU’s output connectors with the actual cords on your servers and networking equipment; C13 and C19 outlets are not interchangeable. A high-capacity unit cannot create more capacity than the upstream circuit provides. Avoid buying on a stated kilowatt figure alone, since usable power depends on the complete electrical path and local operating limits. When the circuit or connector plan is uncertain, have a qualified electrician or facilities specialist verify it before purchase.
Choose monitoring and switching for the job
Metering, managed monitoring, switched outlets, and automatic transfer solve different problems. Metering can help operators track load, while remote outlet switching can support controlled recovery or power cycling; ATS capability addresses a different need by allowing a supported alternate source. These features add complexity and only help when the rack has a suitable network, management process, and compatible redundant feed where required. For a small, stable rack, a simpler PDU may be easier to deploy and maintain. Decide which operational task you need to solve before paying for controls you may not use.
Size racks for equipment, cabling, and growth
Count rack units for the equipment you own, then reserve space for near-term additions, cable management, and any required airflow gaps. Measure equipment depth including handles, connectors, and cable bend space; nominal rack depth does not tell the whole story. Check rail adjustment ranges and whether the rack’s usable depth fits your longest device. A larger rack gives room to grow but needs more floor space and may be harder to place or move. Buying too small can force a second installation, while buying too large can complicate access and cooling in a constrained room.
Pick open frame, enclosed cabinet, or wall mount deliberately
Open frames favor access and visibility, which can suit controlled rooms where airflow and frequent service matter more than a physical enclosure. Cabinets add doors and side panels, but buyers should check ventilation, cable entry, lock design, and whether the room can shed the equipment’s heat. Wall-mounted cabinets save floor area, yet the wall and anchors must support the fully loaded cabinet, not just its empty weight. Glass doors make equipment visible but do not offer the same airflow pattern as a mesh design. Do not select a cabinet based on appearance alone; access, cooling, security, and mounting structure all affect suitability.
Plan installation, mobility, and load support
Check whether the rack arrives assembled or requires assembly, what mounting hardware is included, and whether the equipment can be installed safely in the available space. Casters are useful for repositioning, but a mobile rack needs a stable operating position and a clear plan for cables, thresholds, and floor loading. A cantilever shelf can support equipment that lacks rack ears, yet it takes rack space and its load rating must suit the device. Cage nuts and screws are small purchases that can prevent installation delays, but confirm thread size and rail compatibility before ordering bulk quantities. For heavy or tall equipment, plan lifting help and anchoring rather than treating setup as a one-person task.
Account for heat, service access, and future maintenance
Rack equipment concentrates heat, so room cooling and air paths matter as much as a cabinet’s listed fan or door design. Keep intake and exhaust paths clear, avoid blocking vents with cabling, and plan for hot spots that may appear as equipment density rises. A cabinet fan is not a substitute for room-level cooling or a verified airflow plan. Leave working clearance for door swing, rear access, and replacing components without disturbing neighboring gear. Favor a layout that makes inspection and cable changes manageable, since poor access can turn routine maintenance into avoidable downtime.
Frequently Asked Questions
Should I choose a switched ATS PDU or a metered PDU?
Choose based on the task you need the PDU to perform. A metered model is aimed at viewing power use, while a switched ATS model adds outlet control and automatic transfer features that may suit a more demanding power setup. ATS functionality is useful only when the source arrangement and connected equipment support the intended failover plan. If you only need distribution and basic load visibility, the extra controls may add management work without solving a current problem. Verify the exact model’s monitoring, transfer, and outlet-control functions against its documentation before deciding.
How much rack depth should I leave beyond the server’s listed depth?
Do not match rack depth to the chassis measurement alone. Add room for rear connectors, cable bend radius, rail hardware, airflow, and access to service parts. Measure the longest installed device in its final configuration, then compare that measurement with the rack’s usable rail depth and adjustment range. Manufacturers may describe overall cabinet depth differently from usable equipment depth, so check the dimension drawings. If you expect deeper hardware later, extra usable depth can prevent a costly rack replacement.
Is an open-frame rack suitable for a small office or shared room?
It can work when the room is controlled, access is limited to authorized people, and the installation benefits from open access and airflow. An open frame offers less physical shielding than an enclosed cabinet and leaves equipment more exposed to accidental contact, dust, or cable disturbance. In a shared space, a lockable cabinet may provide a better boundary, although it still needs appropriate ventilation and service clearance. Consider noise and the location of the rack as well as security. The right choice depends on room access and cooling plans, not rack capacity alone.
What should I check before mounting a wall cabinet?
Check the loaded weight of the cabinet and all planned equipment, then confirm that the wall structure and anchors can support that load. A wall-mounted cabinet may become far heavier after servers, switches, PDUs, and cabling are installed. Verify cabinet depth against the devices and the space needed for connectors, doors, and service access. Plan cable entry and ventilation before drilling, and follow the cabinet and anchor manufacturers’ installation guidance. If the wall construction or load capacity is unclear, get a qualified installer to assess it.
Can I use a rack shelf instead of rack-mount rails?
A shelf can support devices without rack ears when its dimensions and load rating match the equipment, but it is not a universal replacement for rails. Check whether the shelf is cantilevered or supported at multiple points and confirm its stated capacity under the expected load. The device should sit securely, with vents unobstructed and cables routed without pulling it forward. A shelf also consumes rack space that may be needed for equipment mounted directly to rails. For heavy hardware, use the mounting approach approved by its manufacturer whenever possible.
Conclusion
For a balanced shortlist, I would choose the CyberPower PDU44002 Switched ATS as the best overall pick when outlet control and transfer capability fit the power design, and the StarTech.com 42U Open Frame Rack for a flexible full-height rack in a controlled room. The CyberPower PDU24004 is the best value direction for buyers seeking metered ATS distribution without the switched features of the PDU44002; confirm its electrical fit before purchase. For a premium-style managed power choice, consider the Eaton ePDU G3 when its management features and 120V, 12A rating suit the deployment. Beginners building a compact installation may find a wall cabinet easier to size than a full-height rack, with the Tecmojo 9U offering a small enclosed format. For specific needs, pick the 18U mesh-door cabinet when ventilation and wall mounting lead, the Sysracks 22U cabinet when deeper equipment needs enclosed space, and the ElaraBerry shelf for compatible gear without rack ears. I would settle the power and measurement checks first, then choose the enclosure or frame that fits the room and leaves workable service access.
Fall Picks
fall essentials
As an affiliate, we earn on qualifying purchases.
